As an important detection method for molecular biology detection, real-time fluorescence quantitative PCR has been widely used in many fields such as scientific research, clinical detection and diagnosis and forensic applications.
- Four channels and six channels cover most fluorescence;
- Effectively reduces multi-color crosstalk and edge effects without fluorescence correction;
- Innovative scanning method and time-resolved signal separation technology ;
- Optical scanning detection system, high sensitivity and resolution, accurateidentification of negative and positive;
- Unique zoned temperature control and edge temperature compensation technology ensures temperature uniformity.
Model | QP96C4 | QP96C6 |
Sample capacity | 96x0.1ml PCR tube/12x0.1ml 8-strip tube/96-well microplate | |
Reaction volume | 10~50μl | |
Thermal cycling | Peltier(6 temperature control modules) | |
Maximum ramp rate | 6℃/s | |
Temperature setting range | 4~100℃ | |
Temperature accuracy | ≤ ±0.1℃ | |
Temperature uniformity | ≤±0.1℃ | |
Gradient zone | 12 columns | |
Gradient range | 1~40°C | |
Excitation light source | 4pcs LED | 6pcs LED |
Detection module | MPPC | |
Scanning principle | Time-resolved scanning technology | |
Excitation/detection range | 415-685nm/455-745nm | |
Fluorescence channel | 4 channels | 6 channels |
Detection sensitivity | 415-685nm/455-745nm | |
Excitation/detection range | 1 copy of the target sequence | |
System sensitivity | 1.33-fold copy number differences in singleplex reactions | |
Dynamic range | 10 orders of magnitude | |
Dye compatibility | F1: FAM/SYBR Greenl F2: VIC/HEX/TET/JOE/TAMRA F3: ROX/Texas Red F4: Cy5/LIZ F5: Quasar 705/AlexaFluor 680/Cy5.5 F6: ATTO425 | |
Dimension | L500xW360xH380mm | |
Weight | 25kg | |
Power supply | 100-240V，50-60Hz | |
