The thermal cycler is basic instrument in molecular laboratories and is mainly used for gene amplification in scientific research and clinical area, qualitative PCR gene amplification, gene chip or other gene analysis applications. The gradient thermal cycler has gradient function, which can quickly increase and decrease the temperature. lt can achieve temperature uniformity in a single process and can quickly and stably complete polymerase chain reaction (PCR) experiments.
- Portable and compact design;
- Elastic structure hot lid design, adaptable to 96-well microplate or 0.1 /0.2ml PCR tube;
- Using high-quality peltier, ensure excellent temperature uniformity;
- The heating and cooling rate can reach to 5.5°C/s, saving experimental time;
- Humanized standard program file template, which can quickly edit experimental files;
- Automatic fault detection and alarm function.
Model | TC96S | TC96G |
Temp mode | Standard | Gradient |
Sample capacity | 96×0.1/0.2mL PCR tube/96-wells PCR Plate | |
Reaction volume | 10~50μl | |
Block temp control range | 4~105°C | |
Hot lid temp control range | 30~110°C | |
Temp display accuracy | ±0.1°C | |
Temp control accuracy | ±0.3°C | |
Temp uniformity | ±0.3°C at 55℃ | |
Max temp change rate | 5.5°C/s | |
Gradient setting range | / | 30~105°C |
Gradient spread | / | 1~42°C |
Gradient temp. uniformity | / | ±0.3°C at 55℃ |
Gradient temp. accuracy | / | ±0.3°C at 55℃ |
Heating and cooling system | Petier temperature control | |
Display | 7-inch color touch screen | |
Memory capacity | 700 files | |
Max. number of cycle | 100 | |
Power outage protection | Yes | |
Dimension | L270×W240×H150mm | |
Weight | 4.8kg | |
Voltage/Frequency | 100~240V;50/60Hz | |
