Specification

- Comfortable human-machine operation interface, to display the whole running and time/ speed setting information,convenient for real-time observation

Adopting PID temperature control technology, built-in temperature calibration function and compact constant temperature space, to ensure the accuracy and uniformity of experimental temperature

Unique speed control circuit, to ensure smooth starting for the shaker and prevents liquid splashing and damage to the instrument

DC brushless motor driving, large starting torque, low noise, low interference, maintenance-free, long-term continuous operation and long lifetime

Automatic recovery for setting data after power off, automatic pause function when opening the cover, high safety

Built-in double over-temperature protection device, much safer to use



Model

TSH-O2

TSH-O3

TSH-O2C

TSH-O3C

Temp. setting range

0℃~60℃

Temp. control range

RT +5℃~60℃

5℃~60℃(RT drops by 20℃)

Time setting

1min~99h59min/∞

Temp. control accuracy

≤±0.5℃(@37℃)

Display accuracy

0.1℃

Temp uniformity

≤±0.5°℃(@37℃)

Speed range

50-300rpm

Shake amplitude

20mm horizontal rotation

Standard tray

Universal tray

Platform size

230x230mm

350x350mm

230x230mm

350x350mm

Inner cavity height

182mm

300mm

182mm

300mm

Loading weight

4.0Kg

10.0Kg

4.0Kg

10.0Kg

Heating time

≤15min(25℃ to 60°C)

Automatic recovery after power off

Yes

Automatic pause when cover is open

Yes

Input power

350W

600W

500W

900W

Fuse

250V 3A Φ5x20

250V 6A Φ5x20

250V 4A Φ5x20

250V 6A Φ5x20

Dimensions

L421xW320xH338mm

Weight

18.5Kg

32.5Kg

20Kg

39.5Kg

Power supply

110V/220V;50/60HZ
