Mainly used for efficient homogenization and emulsification between two immiscible liquid, and extraction of trace organic compounds, fat-soluble substances and organic solvent-soluble substances in water.
Widely application as an experimental instrument in scientific research institutions, colleges and universities, environmental protection, sanitation and epidemic prevention, chemical industry, water supply, medical units.
Features
- DC high-speed motor, strong power, stable operation, low heat, long lifetime, lower energy consumption
- High-definition digital display screen, real-time display to guarantee for collecting experimental data
- Stainless steel probe, corrosion-resistant and high-temperature resistant
- 2 specifications of probe to meet the needs of different experiments
- Stepless speed knob, accurately setting the speed within the range of 2000~20000rpm
Technical parameters
Model | TH200D |
Power | 200W |
Power adapter | 24V 6A |
Speed range | 2000~20000rpm |
Adjustment method | Knob Infinitely Variable Speed Control |
Maximum viscosity | 5000 mPa.s |
Set 1: Small capacity probe | Diameter: 12m, Length: 15cm, Processing Capacity: 20-1000mL |
Set 2: Large capacity probe | Diameter: 18mm, Length:16cm, Processing Capacity:20-1200mL |
Material of touching sample | Stainless Steel and Polytetrafluoroethylene (PTFE) |
Protection level | IP20 |
Motor | Direct Current High-Speed Motor |
Diameter (including stand) (LxWxH) | L360mm×W320mm×H600mm |
Weight | 4kg |
Input voltage/frequency | 100~240V 50/60Hz |
