Specification

1. High sensitivity and high resolution

Can detect low concentrations of DNA/RNA and identify and distinguish very close bands, low background noise, high dynamic range;

2. High-resolution autofocus lens

Provides clear image details, improves operating experience and avoids human operation errors;

3. Modular design, flexible application expansion

Can choose fluorescence module, white light transillumination module, blue light transillumination module according to experimental needs;

4. The software is intuitive and friendly, with complete functions

Ensure accurate and rapid electrophoresis images and analysis results, and improve experimental efficiency;

5. Flexible control method

Touch screen/external computer one-key switching solution to meet the operating habits of different users.



Model

GIS810U

Camera

8 megapixels

Lens

High-resolution auto-focus lens

Display

13.3-inch touch screen

Working area

21cm*26cm

LED light source

Built-in LED UV/blue light/white light

LED Lifetime

>30000 h

Max. excitation wavelength

Blue light: 470nm; UV: 302nm

Dimension

L400×W400×H500mm

Weight

50KG

Power supply

220V50/60HZ


Applications

Nucleic acid detection:

Compatible with a variety of nucleic acid dyes, such as EB, Gel Signal Red, Gel Signal Green, SYBR Gold, SYBR Green, SYBR Safe, Gel Star, etc.;

Protein detection:

Coomassie brilliant blue gel, silver staining gel, etc.;

Other applications:

Culture dish colony imaging, etc.
