Specification

- Unique built-in bottom LED UV light source, lower power consumption and long lifetime;

LED UV lamp beads make the wavelength more concentrated and shorter radiation distance which greatly reduce harmfulness to the human body;

Bottom UV light source irradiation, no reflected light interference, high observation and imaging quality;

Uniform brightness, effectively excite gel sheet and make bands clearer;

Adjustable light intensity and contrast according to the different experiment purposes and environment, can achieve  the best observation or imaging quality;

Superconducting heat dissipation, no noise, provide comfortable experimental environment;

Stable aluminum alloy base, only 30mm thickness, lightweight and compact;

Automatically shuts down after 5 minutes, guarantee the operator or transilluminator safety;

Different observation areas are available:150*120mm/200*130mm.


Model

TI302S

TI302Pro

Observation area

L150×W120mm

L200×W130mm

Power

12V 1A

LED source

UV LED light

LED lifetime

50,000h

Emission wavelength

302nm

Auto shutdown time

5min

Dimension

L260×W192×H30mm

Weight

1.3kg

Voltage/Frequency

100~240V;50/60Hz
